Supermicro SYS-6019P-MTR

The Supermicro SYS-6019P-MTR is a high-performance 1U rackmount server designed for enterprise and data center applications. It supports dual Intel Xeon Scalable processors (1st or 2nd Gen), offering powerful compute capabilities for demanding workloads. Key features include up to 2TB of DDR4 ECC memory across 16 DIMM slots, flexible storage with 10 hot-swap 2.5″ drive bays (supporting SATA/SAS/NVMe), and dual 1GbE LAN ports for reliable networking. The system also includes redundant 750W Platinum-level power supplies for high availability. Its compact design, scalability, and robust performance make it ideal for virtualization, cloud computing, and high-density environments.

Brand:Supermicro
Products Status:New
Product SKUs:SYS-6019P-MTR
Form Factors:1U

$Quote1 Piece(MOQ)

Bulk Order Discounts Available

Product SKUs

SYS-6019P-MTR
  • SuperServer 6019P-MTR (Black)

Motherboard


Super X11DPL-i

Processor/Cache

CPU
  • Dual Socket P (LGA 3647)
  • 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors,
    Dual UPI up to 10.4GT/s
  • Support CPU TDP 70-140W
Cores
  • Up to 28 Cores
Note  BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R)

System Memory

Memory Capacity
  • 8 DIMM slots
  • Up to 2TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM
Memory Type
  • 2933/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM
Note  2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro

On-Board Devices

Chipset
  • Intel® C621 chipset
SATA
  • SATA3 (6Gbps); RAID 0, 1, 5, 10
Network Controllers
  • Marvell 88E1512 PHY Gigabit Ethernet controller
  • Supports 1000BASE-T
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Video
  • ASPEED AST2500 BMC

Input / Output

SATA
  • 4 SATA3 (6Gbps) ports
LAN
  • 2 RJ45 Gigabit Ethernet LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 2 USB 2.0 ports (rear)
Video
  • 1 VGA port
Serial Port / Header
  • 1 COM port (header)
DOM
  • 2 SuperDOM (Disk on Module) ports

System BIOS

BIOS Type
  • 256Mb SPI Flash EEPROM with AMI BIOS

Management

Software
  • Intel® Node Manager
  • IPMI 2.0
  • KVM with dedicated LAN
  • NMI
  • SSM, SPM, SUM
  • SuperDoctor® 5
  • Watch Dog
Power Configurations
  • ACPI / APM Power Management

PC Health Monitoring

CPU
  • Monitors for CPU Cores, Chipset Voltages, Memory.
  • 4+1 Phase-switching voltage regulator
FAN
  • Fans with tachometer monitoring
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors
Brand

Supermicro

Products Status

New

Product SKUs

SYS-6019P-MTR

Form Factors

1U
