| BIOS Features | Plug and Play (PnP)APM 1.2PCI 2.3DMI 2.3ACPI 1.0 / 2.0 / 3.0 / 4.0USB Keyboard supportHardware BIOS Virus protectionSMBIOS 2.7.1UEFI 2.3.1 |
|---|---|
| Graphics | 1 ASPEED AST2400 BMC port(s) |
| TPM | 1 TPM Header |
| Network Controllers | Quad LAN with Intel Ethernet Controller I210-AT |
| M.2 | M.2 Interface: PCIe 3.0 x2Form Factor: 2280Key: M-Key |
| Chipset | Intel C236 |
| DIMM Sizes | 16GB, 4GB, 8GB |
| BIOS Type | 128MB SPI Flash EEPROM with AMI BIOS |
| Video Output | 1 VGA port(s) |
| Dimension | 9.6" x 9.6" (24.38cm x 24.38cm) |
| PCIe | 1 PCIe 3.0 x4 (in x8 slot), 1 PCIe 3.0 x8, 1 PCIe 3.0 x8 (in x16 slot) |
| USB | 6 USB 2.0 port(s) (4 via header; 2 rear)2 USB 3.0 port(s) (2 rear)3 USB 3 port(s) (2 via header; 1 type A) |
| Form Factor | Micro-ATX |
| Memory Type | 2400/2133/1866/1600 MT/s SDRAM 72-bit, 288-pin gold-plated DIMMs |
| Application | Server |
| IPMI | ASPEED AST2400 BMC |
| Memory Voltage | 1.2V |
| CPU | CPU TDP supports Up to 80W TDP, Intel 7th/6th Generation Core i3 series, Intel Celeron, Intel Pentium, Intel Xeon processor E3-1200 v6/v5Single Socket Socket H4 (LGA-1151) supported |
| Serial Port | 2 COM Port(s) (1 header; 1 rear) |
| SATA | 1, 10, 5, Intel C236 controller for 8 SATA3 (6 Gbps) ports; RAID 0 |
| Memory Capacity | 4 DIMM slots64GB Unbuffered ECC UDIMM, DDR4-2400MT/s |
| Error Detection | Corrects single-bit errors |
Supermicro MBD-X11SSH-LN4F-B
The Supermicro MBD-X11SSH-LN4F-B is a high-performance micro-ATX server motherboard designed for Intel Xeon E3-1200 v5/v6 processors and 6th/7th Gen Intel Core CPUs, supporting up to 64GB DDR4 ECC/non-ECC UDIMM memory. Key features include four Intel Gigabit LAN ports for advanced networking, dual Intel i210 and dual i219 controllers for enhanced reliability, and support for IPMI 2.0 with dedicated LAN for remote management. With six SATA3 ports, one PCIe 3.0 x16, and two PCIe 3.0 x8 slots, it offers excellent expandability. Ideal for small business servers, storage appliances, and virtualization, it delivers enterprise-grade performance, robust connectivity, and remote management in a compact form factor.
| BIOS Features： | Plug and Play (PnP)APM 1.2PCI 2.3DMI 2.3ACPI 1.0 / 2.0 / 3.0 / 4.0USB Keyboard supportHardware BIOS Virus protectionSMBIOS 2.7.1UEFI 2.3.1 |
|---|---|
| Graphics： | 1 ASPEED AST2400 BMC port(s) |
| TPM： | 1 TPM Header |
| Network Controllers： | Quad LAN with Intel Ethernet Controller I210-AT |
| M.2： | M.2 Interface: PCIe 3.0 x2Form Factor: 2280Key: M-Key |
