| BIOS Features | ACPI 6.0SMBIOS 3.0 or laterPlug and Play (PnP) |
|---|---|
| Graphics | 1 ASPEED AST2500 BMC port(s) |
| TPM | 1 TPM Header |
| Network Controllers | Dual LAN with Intel i210 Gigabit Ethernet Controller |
| M.2 | M.2 Interface: 1 PCIe 3.0 x4Form Factor: 2280Key: M-Key |
| Chipset | Intel C422 |
| DIMM Sizes | 128GB, 16GB, 32GB, 4GB, 64GB, 8GB |
| BIOS Type | AMI UEFI |
| LAN | 2 RJ45 Gigabit Ethernet LAN ports |
| Video Output | 1 VGA port(s) |
| DOM | DOM |
| Dimension | 9.6" x 9.6" (24.38cm x 24.38cm) |
| PCIe | 1 PCIe 3.0 x16, 2 PCIe 3.0 x8 |
| USB | 6 USB 2.0 port(s) (4 via header; 2 rear)3 USB 3.2 Gen1 port(s) (2 via header; 1 type A)2 USB 3.0 port(s) (2 rear) |
| Form Factor | Micro-ATX |
| Memory Type | 2933/2666/2400/2133 MT/s ECC DDR4 LRDIMM, RDIMM |
| Application | Server |
| IPMI | ASPEED AST2500 |
| Memory Voltage | 1.2V |
| CPU | CPU TDP supports Up to 165W TDP, Intel Xeon W-2100 Processors, Intel Xeon W-2200 ProcessorsSingle Socket Socket R4 (LGA-2066) supported |
| Serial Port | 2 COM Port(s) (1 header; 1 rear) |
| SATA | 8 SATA3 (6Gbps) port(s) |
| Memory Capacity | 4 DIMM slotsUp to 512GB ECC LRDIMM, DDR4-2933MT/s, DDR4-2933MT/s; Up to 256GB ECC RDIMM |
| Error Detection | Corrects single-bit errors |
| Core | 36 threads, Up to 18 cores |
Supermicro MBD-X11SRM-VF-B
The Supermicro MBD-X11SRM-VF-B is a high-performance ATX server motherboard designed for Intel Xeon E5-2600 v5/v6 processors, offering robust computing power for enterprise and workstation applications. Key features include support for up to 512GB DDR4 ECC Registered memory across 8 DIMM slots, dual Intel Gigabit LAN for reliable networking, and multiple expansion options with 3 PCIe 3.0 x8 slots. It also includes IPMI 2.0 with dedicated LAN for remote management, enhancing system control and uptime. Its reliability, scalability, and remote management capabilities make it ideal for demanding business environments.
| BIOS Features： | ACPI 6.0SMBIOS 3.0 or laterPlug and Play (PnP) |
|---|---|
| Graphics： | 1 ASPEED AST2500 BMC port(s) |
| TPM： | 1 TPM Header |
| Network Controllers： | Dual LAN with Intel i210 Gigabit Ethernet Controller |
| M.2： | M.2 Interface: 1 PCIe 3.0 x4Form Factor: 2280Key: M-Key |
