- Dual Socket E (LGA-4677) 5th/4th Gen Intel? Xeon? Scalable processors
- Up to 4TB 3DS ECC RDIMM, DDR5-5600MT/s(1DPC) in 16 DIMM slots
-
- 1x GbE Dedicated LAN for server remote management: IPMI 2.0 / KVM over LAN / Media over LAN
- 2x 10 GbE onboard via Broadcom BCM57416
- 36x 3.5″/2.5″ Hot-swap SAS3/SATA3 drives, 2x Rear 2.5″ SATA Slots, 2x NVMe M.2 (form factor: 2280 and 22110)
- 7x 8cm hot-swap counter-rotate redundant PWM cooling fans
- 1600W Redundant Power Supplies Titanium Level (96%)
- HBA Controller support via Broadcom? 3808
Storage SuperServer SSG-641E-E1CR36L
The Storage SuperServer SSG-641E-E1CR36L is a high-performance, enterprise-grade storage server designed for data-intensive applications. It features support for up to 36 hot-swappable 3.5″ SATA/SAS drives in a 4U form factor, delivering massive storage capacity. Powered by a single 3rd Gen Intel Xeon Scalable processor, it offers robust computing performance with up to 2TB of DDR4 memory. Key benefits include high-density storage, advanced RAID support via an integrated Broadcom 3108 controller, and optimized airflow for efficient cooling. Its unique selling points are its exceptional storage scalability, enterprise reliability, and suitability for applications like data archiving, cloud storage, and video surveillance.
| Brand： | Supermicro |
|---|---|
| Products Status： | New |
| Form Factor： | 4U Rackmount |
| Model： | SSG-641E-E1CR36L |
| Application： | Server |
$Quote1 Piece(MOQ)
Bulk Order Discounts Available
⚠️ Wholesale & B2B Inquiries Only! We partner exclusively with established businesses for bulk procurement, no individual, personal, or retail orders.
| Brand | Supermicro |
|---|---|
| Products Status | New |
| Form Factor | 4U Rackmount |
| Model | SSG-641E-E1CR36L |
| Application | Server |
| Chassis Form Factor | 4U Rackmount |
| Height | 7" |
| Width | 17.2" |
| Depth | 27.5" |
| Chipset | Intel C741 |
| Weight | Net Weight: 65.5 lbs (29.7 kg) Gross Weight: 102.5 lbs (46.4 kg) |
| Memory | Slot Count: 16 DIMM slots Max Memory (1DPC): Up to 4TB 5600MT/s ECC DDR5 RDIMM |
| CPU | Dual Socket E (LGA-4677) 5th Gen Intel Xeon / 4th Gen Intel Xeon Scalable processors |
| Motherboard | Super X13DEI-T |
| Product SKUs | SuperServer SSG-641E-E1CR36L (Silver) |
| Chassis Model | CSE-847BTS-R1K68LPBP5 |
| Note | Supports up to 270W TDP CPUs (Air Cooled) |
| Network Connectivity | 2x 10GbE BaseT with Broadcom BCM57416 |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| Package | 15" (H) x 27" (W) x 39" (D) |
| Memory Voltage | 1.1V |
