| Memory Types | DDR4 2933 |
|---|---|
| Code Name | Cascade Lake |
| Max # of Memory Channels | 4 |
| TDP | 105 W |
| Hyper-Threading Support | Yes |
| Model | CD8069504394102 |
| Total Threads | 8 |
| Physical Address Extensions | 46-bit |
| Manufacturing Tech | 14 nm |
| PCI Express Revision | 3 |
| Shipping Media | TRAY |
| Max CPU Configuration | 1 |
| PCI Express Configurations | x16, x4, x8 |
| Bus Speed | 8 GT/s |
| ECC Memory Supported | Yes |
| Brand | Intel |
| Embedded Options Available | No |
| Processor Base Frequency | 4.10 GHz |
| Scalability | 1S Only |
| Max Turbo Frequency | 4.60 GHz |
| 64-Bit Support | Yes |
| Series | Intel Xeon W |
| Package Size | 45mm x 52.5mm |
| Max # of PCI Express Lanes | 48 |
| Max Memory Bandwidth | 93.85 GB/s |
| CPU Socket Type | FCLGA2066 |
| Application | Workstation |
| Cache | 8.25 MB |
| Part Number | W-2225 |
| Total Cores | 4 |
| Max Memory Size | 1 TB |
| Products Status | New |
| Instruction Set | 64-bit |
Intel Xeon W-2225 Processor (8.25M Cache, 4.10 GHz)
The Intel Xeon W-2225 is a high-performance workstation processor designed for professional creators and demanding workloads. Featuring 4 cores, 8 threads, a base clock speed of 4.10 GHz, and 8.25MB of Smart Cache, it delivers fast, reliable performance for tasks like 3D rendering, video editing, and CAD applications. Built on Intel’s scalable Xeon architecture, it supports ECC memory for enhanced data integrity and reliability. With Intel Turbo Boost Technology and support for advanced security features, the Xeon W-2225 offers a powerful, stable, and secure platform for professional-grade computing.
| Memory Types： | DDR4 2933 |
|---|---|
| Code Name： | Cascade Lake |
| Max # of Memory Channels： | 4 |
| TDP： | 105 W |
| Hyper-Threading Support： | Yes |
