| Memory Types | DDR3L-1866, DDR4-2400 |
|---|---|
| # of Displays Supported | 3 |
| Code Name | Kaby Lake |
| Max # of Memory Channels | 2 |
| TDP | 73 W |
| Hyper-Threading Support | Yes |
| Model | CM8067702870931 |
| Total Threads | 8 |
| Manufacturing Tech | 14 nm |
| PCI Express Revision | 3 |
| Max CPU Configuration | 1 |
| PCI Express Configurations | 1×16, 1×8+2×4, 2×8 |
| Bus Speed | 8 GT/s |
| ECC Memory Supported | Yes |
| Brand | Intel |
| 4K Support | at 60Hz, Yes |
| Intel Quick Sync Video | Yes |
| Embedded Options Available | Yes |
| Processor Base Frequency | 3.80 GHz |
| Scalability | 1S Only |
| Max Turbo Frequency | 4.20 GHz |
| 64-Bit Support | Yes |
| Series | Intel Xeon E3 v6 |
| Package Size | 37.5mm x 37.5mm |
| DirectX* Support | 12 |
| Max # of PCI Express Lanes | 16 |
| Graphics Max Dynamic Frequency | 1.15 GHz |
| Max Memory Bandwidth | 37.5 GB/s |
| CPU Socket Type | FCLGA1151 |
| Application | Server |
| Graphics Base Frequency | 350 MHz |
| Graphics Output | eDP/DP/HDMI/DVI |
| Cache | 8 MB |
| Part Number | E3-1275V6 |
| Total Cores | 4 |
| Max Memory Size | 64 GB |
| Products Status | New |
| Instruction Set | 64-bit |
| Clear Video HD Technology | Yes |
| OpenGL* Support | 4.4 |
| Device ID | 0x591D |
Intel Xeon Server Processor E3-1275 v6 (8M Cache, 3.80 GHz)
The Intel Xeon E3-1275 v6 is a high-performance server processor designed for entry-level workstations and small business servers. Featuring 4 cores and 8 threads with a base clock speed of 3.80 GHz (up to 4.20 GHz Turbo), it delivers fast, reliable performance for multitasking and demanding workloads. With 8MB SmartCache, support for ECC memory, and integrated Intel HD Graphics P630, it ensures data integrity, efficient processing, and enhanced visual performance. Built on Intel’s 14nm architecture, it offers improved energy efficiency and robust security features, making it ideal for professional-grade applications and 24/7 server environments.
| Memory Types： | DDR3L-1866, DDR4-2400 |
|---|---|
| # of Displays Supported： | 3 |
| Code Name： | Kaby Lake |
| Max # of Memory Channels： | 2 |
| TDP： | 73 W |
