At the heart of your versatile data center, the powerful new Intel Xeon processor E5-2600 v4 product family offers great performance, enhanced orchestration and security across diverse workloads. They are manufactured with 14nm process technology and feature up to 22 cores/44 threads. From virtualization and cloud computing to design automation or real-time financial transactions, you’ll be delighted by better than ever performance and energy efficiency. They also support PCIe 3.0, have AES New Instructions and AVX 2.0 Instruction Set Extensions – power the future of your high-performance computing.
Intel Xeon E5-2620 V4 Broadwell-EP 2.1 GHz 8 x 256KB L2 Cache 20MB L3 Cache LGA 2011-3 85W BX80660E52620V4 Server Processor
The Intel Xeon E5-2620 V4 is a high-performance server processor designed for data centers and enterprise workloads. Featuring 8 cores and 16 threads, it runs at a base frequency of 2.1 GHz and is built on the Broadwell-EP architecture. With 8 x 256KB L2 cache and a 20MB shared L3 cache, it delivers efficient multitasking and fast data access. Compatible with the LGA 2011-3 socket and operating at a low 85W TDP, it offers excellent energy efficiency. Key benefits include robust virtualization support, scalable performance for multi-CPU configurations, and reliability for mission-critical applications—making it ideal for servers, virtualization, and cloud computing environments.
| Brand: | Intel |
|---|---|
| Products Status: | New |
| Application: | Server |
| CPU Socket Type: | FCLGA2011 |
| Total Threads: | 16 |
$Quote1 pcs(MOQ)
Minimum Order Quantity
1 pcs(MOQ)
Minimum Order Quantity
Bulk Order Discounts Available
| Brand | Intel |
|---|---|
| Products Status | New |
| Application | Server |
| CPU Socket Type | FCLGA2011 |
| Total Threads | 16 |
| Total Cores | 8 |
| Cache | 20 MB |
| TDP | 85 W |
| Manufacturing Tech | 14 nm |
| Processor Base Frequency | 2.10 GHz |
| Memory Types | DDR4 1600/1866/2133 |
| Series | Intel Xeon E5 v4 |
| Part Number | E5-2620V4 |
| Model | CM8066002032201 |
| Hyper-Threading Support | Yes |
| Max Memory Size | 1.5 TB |
| Code Name | Broadwell |
| Max Turbo Frequency | 3.00 GHz |
| 64-Bit Support | Yes |
| Max # of Memory Channels | 4 |
| Max # of PCI Express Lanes | 40 |
| PCI Express Revision | 3 |
| Package Size | 45mm x 52.5mm |
| Embedded Options Available | Yes |
| Scalability | 2S |
| ECC Memory Supported | Yes |
| Max CPU Configuration | 2 |
| Instruction Set | 64-bit |
| PCI Express Configurations | x16, x4, x8 |
| Max Memory Bandwidth | 68.3 GB/s |
| Bus Speed | 8 GT/s |
| Physical Address Extensions | 46-bit |
