AMD Ryzen 5 7600X CPU Socket AM5 Desktop processor
The AMD Ryzen 5 7600X is a high-performance desktop processor designed for the AM5 socket, featuring 6 cores and 12 threads built on the advanced 5nm Zen 4 architecture. With a base clock of 4.7 GHz and boost speeds up to 5.3 GHz, it delivers exceptional speed for gaming and productivity. Key benefits include support for PCIe 5.0 and DDR5 memory, enabling faster data transfer and future-ready performance. Its unlocked multiplier allows for overclocking, while improved power efficiency and integrated Radeon graphics make it a versatile choice for modern PC builds. Ideal for gamers and creators seeking cutting-edge performance at a competitive price.
| Brand： | AMD |
|---|---|
| Products Status： | New |
| Application： | Desktop |
| CPU Socket Type： | AM5 |
| Total Threads： | 12 |
$Quote10 pcs(MOQ)
Bulk Order Discounts Available
| Brand | AMD |
|---|---|
| Products Status | New |
| Application | Desktop |
| CPU Socket Type | AM5 |
| Total Threads | 12 |
| Total Cores | 6 |
| Cache | 32 MB |
| TDP | 105 W |
| Manufacturing Tech | 5 nm |
| Processor Base Frequency | 4.70 GHz |
| Memory Types | DDR5 |
| Series | AMD Ryzen 5 7000 Series |
| Part Number | AMD Ryzen 5 7600X |
| Max Memory Size | 128 GB |
| Code Name | Raphael AM5 |
| Max. Boost Clock | Up to 5.3 GHz |
| PCI Express® Version | PCIe 5.0 |
| Product ID Tray | 100-000000593 |
| Memory Channels | 2 |
| Memory Type | DDR5 |
| Product Family | AMD Ryzen |
| L2 Cache | 6 MB |
| Base Clock | 4.7 GHz |
| *OS Support | RHEL x86 64-Bit, Ubuntu x86 64-Bit, Windows 10 – 64-Bit Edition, Windows 11 – 64-Bit Edition |
| Max. Operating Temperature (Tjmax) | 95C |
| Graphics Model | AMD Radeon Graphics |
| Unlocked for Overclocking | Yes |
| Graphics Core Count | 2 |
| Graphics Frequency | 2200 MHz |
| Regional Availability | Global |
| AMD PRO Technologies | No |
| Consumer Use | Yes |
| Supported Extensions | AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Architecture | Zen 4 |
| Max. Memory | 128 GB |
| NVMe Support | Boot, RAID0, RAID1, RAID10 |
| CPU Compute Die (CCD) Size | 71mm2 |
| Multithreading (SMT) | Yes |
| Native USB 2.0 (480Mbps) Ports | 1 |
| Native USB 3.2 Gen 2 (10Gbps) Ports | 4 |
| Max Memory by Socket | "memoryType":["DDR5-5200"]}], [{"memoryKey2":"2x1R" |
| Native PCIe Lanes (Total/Usable) | 24, 28 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Precision Boost Overdrive | Yes |
| Curve Optimizer Voltage Offsets | Yes |
| AMD EXPO Memory Overclocking Technology | Yes |
