| Memory Types | DDR5 |
|---|---|
| Code Name | Raphael AM5 |
| Max. Boost Clock | Up to 5.7 GHz |
| TDP | 120 W |
| Graphics Core Count | 2 |
| Supported Extensions | AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Total Threads | 32 |
| Max. Operating Temperature (Tjmax) | 89C |
| Base Clock | 4.2 GHz |
| Architecture | Zen 4 |
| Max. Memory | 128 GB |
| Manufacturing Tech | 5 nm |
| Product Family | AMD Ryzen |
| AMD PRO Technologies | No |
| NVMe Support | Boot, RAID0, RAID1, RAID10 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Brand | AMD |
| *OS Support | RHEL x86 64-Bit, Ubuntu x86 64-Bit, Windows 10 – 64-Bit Edition, Windows 11 – 64-Bit Edition |
| CPU Compute Die (CCD) Size | 71mm2 |
| Regional Availability | Global |
| Memory Type | DDR5 |
| Multithreading (SMT) | Yes |
| Native USB 2.0 (480Mbps) Ports | 1 |
| Native USB 3.2 Gen 2 (10Gbps) Ports | 4 |
| Processor Base Frequency | 4.20 GHz |
| Max Memory by Socket | "memoryType":["DDR5-3600"]}, "memoryType":["DDR5-3600"]}], "memoryType":["DDR5-5200"]}, [{"memoryKey2":"2x1R", {"memoryKey2":"2x2R", {"memoryKey2":"4x1R", {"memoryKey2":"4x2R" |
| Series | AMD Ryzen 9 7000 Series |
| Memory Channels | 2 |
| ECC Support | Yes (Requires mobo support) |
| Graphics Model | AMD Radeon Graphics |
| Native PCIe Lanes (Total/Usable) | 24, 28 |
| Precision Boost Overdrive | Yes |
| CPU Socket Type | AM5 |
| Application | Desktop |
| Product ID Tray | 100-000000908 |
| Cache | 128 MB |
| Part Number | AMD Ryzen 9 7950X3D |
| Graphics Frequency | 2200 MHz |
| L2 Cache | 16 MB |
| Total Cores | 16 |
| Consumer Use | Yes |
| Max Memory Size | 128 GB |
| Products Status | New |
| Curve Optimizer Voltage Offsets | Yes |
| AMD EXPO Memory Overclocking Technology | Yes |
| PCI Express® Version | PCIe 5.0 |
AMD 9 7950X3D CPU Socket AM5 Desktop processor
The AMD Ryzen 9 7950X3D is a high-performance desktop processor designed for gamers and creators, featuring 16 cores and 32 threads for exceptional multitasking and processing power. Built on the advanced 5nm Zen 4 architecture and compatible with the AM5 socket, it integrates AMD’s 3D V-Cache technology, delivering up to 144MB of cache for significantly improved gaming performance. With a base clock of 4.2GHz and boost speeds up to 5.7GHz, it offers top-tier speed and responsiveness. Its energy-efficient design and PCIe 5.0 and DDR5 support make it a future-ready choice for premium desktop builds.
| L3 Cache： | 128 MB |
|---|---|
| Memory Types： | DDR5 |
| Code Name： | Raphael AM5 |
| Max. Boost Clock： | Up to 5.7 GHz |
| TDP： | 120 W |
